Painted aluminum sheets have been coated with a layer of paint for aesthetic and protective purposes. PE/PVDF painted aluminum sheets are widely used in various industries and applications due to their lightweight, durability and resistance to corrosion.
Painted aluminum sheets redefining design and function across industries. From architectural facades to interior accents, signage, and beyond, these sheets combine corrosion resistance with vibrant aesthetics to create solutions that stand the test of time. Available in a wide range of colors and finishes, our premium painted aluminum sheets offer the strength of metal with the style you’ve been looking for.
Specification of Painted Aluminum Sheet:
Alloy | 1050, 1060, 1070, 1100, 3003, 5052, 5052, 5005, 5006, 5052, 5754, 5182 |
Thickness | 0.2-1.5mm |
Width | 600-1500mm |
Coating Surface | PVDF/ PE/HDP/FEVE/EOXY/ PU |
Coating Thickness | Single Coating (4-20 Um) |
Double Coating (25-28 Um) |
Triple Coating (35-38 Um) |
Temper | O,H12,H22,H14,H24,H16,H26,H18,H26,etc. |
Color | All Ral Color or As Request |
Type | Coil, Sheet, Strips, Plate, Foil |
Applications | Roofing System and Ceiling Decoration for Airport, Railway Stations, Exhibition Halls, Factory and Stadium |
Supply Ability | 200000 tons per year |
MOQ | 2 tons per size |
Standards and Specifications
ASTM | B209 |
ISO | ISO 26204 (alloy designations), ISO 6892 (mechanical testing),ISO 9001,ISO 14001. |
UNS | A91050 (United States Numbering System) |
Coating Options:
The choice of coating for painted aluminum sheets can be considered according to the needs of its application field and project cost.
- Polyester Coating: A common choice for outdoor applications due to its durability and resistance to fading.
- PVDF (Polyvinylidene Fluoride) Coating: Offers superior weathering, UV resistance, and a long lifespan, often used for architectural applications.
Warrantly：
Regular PE: 3-5 years；
High Performance PE: 6-9 years；
PVDF: 15 years；
FEVE: Two coats: between 10-15 years；
FEVE: Three coats: 15-20 years.
Technical Data:
Coating | POLYESTER | PVDF |
Item | Technical requirements | Technical requirements |
Thickness of coating film | ≥ 18 µm | ≥ 25µm |
Gloss deviation | gloss<70, tolerance≤10% | gloss<70, tolerance≤10% |
gloss≥70, tolerance≤5% | gloss≥70, tolerance≤5% |
Hardness of pencil | ≥3H | ≥3H |
Adhesion | no lower than class 1 | no lower than class 1 |
Flexibility | ≤2T | ≤2T |
Boiling water resistance | no change (2h) | no change (2h) |
Color difference | ΔE≤2.0 | ΔE≤2.0 |
MEK | ≥100 times | ≥150 times |
Color Options
The standard color of painted aluminum sheets is modulated according to the Ral color card. The basic colors are red, yellow, blue, green, white, gray and other colors and their derivative colors, which are suitable for most conventional applications.
The Metallic color of painted aluminum sheets simulate metal textures, such as silver gray, bronze, rose gold, etc., which add a sense of luxury and class to the product and are often used in high-end architectural decoration.
The printing series achieve natural texture effects such as wood grain and stone grain through special coating technology, providing more diversified choices for architectural design, esuitable for places that pursue natural and environmental protection concepts.
1000 Vs 3000 Vs 5000 Series Painted Aluminum Sheet
Model | 1000 Series Painted Aluminum Sheet | 3000 Series Painted Aluminum Sheet | 5000 Series Painted Aluminum Sheet |
Main Composition | High-Purity Aluminum (≥99%) | Al-Mn Alloy | Al-Mg Alloy |
Strength | Relatively Low, Easy To Form | Medium Strength, Better Impact Resistance | High Strength, Excellent Tensile Properties |
Corrosion Resistance | Good, Suitable For General Environments | Better, Suitable For Outdoor And Humid Conditions | Excellent, Ideal For Marine And High Salt-Spray Environments |
Workability | Easy To Process, Great Ductility | Good Workability | Good Workability |
Cost | Low-Economical Option | Medium-Good Cost-Performance Ratio | Higher-For Premium Applications |
Typical Applications | Building Decoration, Packaging, Interior Use | Roofing Sheets, Wall Panels, Insulation Boards | Shipbuilding, Marine Projects, Transportation, Industrial Structures |
Surface Finish & Coating Compatibility | • Good Surface Smoothness
• Suitable For Basic PE Coating | • Better Coating Adhesion
• Compatible With PE Coating
• Compatible With PVDF Coating | • Excellent Surface Stability
• Ideal For High-End PVDF Coating
• Suitable For FEVE Coating |
Weather / UV Resistance | • Suitable For Indoor Use
• Suitable For Mild Outdoor Conditions | • Suitable For Long-Term Outdoor Use
• Resistant To Humid Environments | • Excellent For Extreme Climates
• Suitable For Marine Environments
• Resistant To Industrial Pollution |
Service Life | • Short To Medium Term | • Medium To Long Term
• Approx. 10–15 Years | • Long-Lasting Durability
• 20+ Years Of Performance |
Structure of Painted Aluminium Sheet
Process of Painted Aluminium Sheets:
Advantages of Painted Aluminum Sheet Metal:
Aluminum is much lighter than other metals like steel, making it easier to transport and install, which is particularly advantageous in construction and manufacturing.
The natural oxide layer on aluminum provides inherent resistance to corrosion. The added paint layer further protects the aluminum from environmental factors, including moisture and chemicals.
Available in a wide range of colors, finishes, and textures, painted aluminum sheets can be customized to fit specific design requirements, making them ideal for architectural and artistic applications.
The paint coating can enhance the surface hardness of the aluminum, providing additional protection against scratches and wear. This makes them suitable for high-traffic areas and outdoor environments.
Painted aluminum sheets require minimal maintenance. Regular cleaning with mild detergents can keep them looking new, and they are less prone to rust compared to steel.
Applications of Painted Aluminium Sheets:
Used for exterior cladding, roofing, and interior panels in commercial and residential buildings. They provide an attractive finish while offering structural integrity.
Ideal for outdoor signs due to their lightweight nature and resistance to fading and weathering. They can be printed directly or coated with vinyl.
Employed in manufacturing vehicle body panels, trims, and components where weight reduction contributes to fuel efficiency.
Found in various appliances, including refrigerators, ovens, and microwaves, where aesthetics and durability are essential.
Used in the production of trailers, buses, and other vehicles where lightweight materials are necessary for efficiency.
Packaging:
1) LCL by wooden pallet package, fumigation wooden pallet is available
2) FCL by wooden pallet package loaded in the container
3) FCL in bulk loaded in the container
4) Customized package according to your demands
Shipping:
7-15 days after receipt of payment(depend on order quantity)
