RAL 7016 aluminium sheet is also known as anthracite grey aluminum sheet, which is a widely used color of painted aluminum sheet product. RAL 7016 anthracite grey color is very popular in architectural and industrial design, especially in the exterior design of modern buildings.

Specification of RAL 7016 aluminium sheet:

Material: Commonly used are 3003-H24 (corrosion resistant, cost-effective) and 5052-H32 (high strength, fatigue resistant).

Thickness: Typical range: 0.15 mm to 1.5 mm (customizable upon request)

Width: Common range: 1000 mm to 2000 mm (customizable upon request). Specific widths: 1000 mm, 1250 mm, 1500 mm, 2000 mm

Length: Length is usually customizable according to project requirements; common lengths are 2000 mm, 2500 mm, 3000 mm, etc.

Coating Types:

PE Coating: Color coating process, available in matte or glossy finishes, directly presenting RAL 7016 coal gray;

Fluorocarbon Coating (PVDF): Ultra-weather resistant, suitable for outdoor curtain walls, maintaining color stability over long periods;

Coating Thickness: PE coating is typically 10-25μm, fluorocarbon coating 20-35μm to enhance corrosion resistance.

Key features of aluminium sheet RAL 7016:

- Color characteristics:

RAL 7016 is a dark gray tone with low surface reflectivity, reducing the urban heat island effect; it also effectively conceals dirt and wear, reducing maintenance frequency, making it especially suitable for long-term outdoor exposure.

- Weather resistance and corrosion resistance:

The fluorocarbon coating process gives the painted aluminum sheet superior weather resistance, resisting UV rays, acid rain, and other corrosion, with a service life of 15-20 years; The aluminum substrate itself forms a dense oxide film, which, combined with the coating treatment, further enhances corrosion resistance, making it suitable for coastal or highly polluted environments.

- Lightweight and high strength:

Aluminum sheets have a density of only 2.7-2.8 g/cm³, more than 60% lighter than steel, significantly reducing structural load.

Through alloying (such as adding magnesium and zinc) and heat treatment processes (such as T6 temper), tensile strengths of 436-486 MPa can be achieved, meeting high-strength requirements.

- Processing adaptability

Supports laser cutting, stamping, bending, and other processes, and can be customized into complex shapes. High surface flatness and strong coating adhesion ensure uniform color after processing.

Typical applications of RAL 7016 aluminium sheet:

1. Building facade

Curtain wall systems: RAL 7016 grey aluminum sheets are commonly used in building curtain wall systems, providing a modern look and visual impact, while also offering good weather resistance and waterproofing.

Balconies and railings: Used for decorating balcony railings or balconies, providing both aesthetics and sufficient safety.

Roofing decoration: Can be used as roofing material, providing good waterproofing and thermal insulation.

2. Interior decoration

Wall decoration: RAL 7016 aluminum sheets can be used for interior wall decoration, creating a modern and minimalist spatial atmosphere.

Ceilings: In commercial spaces and office environments, aluminum sheets can be used as ceiling materials, providing an aesthetically pleasing visual effect and good acoustic performance.

Exhibition and Display: Used as display panels in exhibition halls, museums, and other venues to enhance the overall design.

3. Commercial and retail environments

Shop exteriors: In shop exterior design, RAL 7016 aluminum sheets can be used as signage, facade elements, or decorative elements to attract customer attention.

Display shelves: Used to create display shelves and racks that are both durable and aesthetically pleasing.

4. Transportation sector

Public transportation facilities: In public transportation facilities such as bus stops and subway stations, RAL 7016 aluminum sheets can be used for components such as bus shelters and platform edges.

Vehicle exteriors: Can be used for exterior trim of cars, buses, or other vehicles, providing a modern look and durability.

5. Industrial Applications

Equipment housings: RAL 7016 aluminium sheet can be used for the housings of industrial equipment, providing protection and enhancing the appearance.

Tools and implements: Used to manufacture housings or components for tools and implements, favored for its lightweight and durability.

6. Furniture manufacturing

Modern furniture: In modern furniture design, RAL 7016 aluminum sheet can be used for tabletops, chairs, cabinets, etc., providing a unique look and durability.

Home furnishings: Used for home décor accessories such as lamps, picture frames, etc.

7. Environmental art

Public art installations: Used for urban public art installations, suitable for outdoor environments due to its weather resistance and aesthetics.

Landscape design: In garden landscape design, RAL 7016 aluminum sheet can be used for elements such as sculptures, fences, and seating.

The applications of RAL 7016 aluminium sheet cover almost all fields, including architecture, interior design, transportation, industry, and furniture. Its excellent physical properties, visual effects, and ease of processing make it an indispensable material in modern design. In practical applications, it is recommended to collaborate with professional designers or suppliers to ensure the best results in material selection and design solutions.
