Colored aluminum sheets utilize high-quality coating materials that effectively resist UV rays, moisture, and salt spray, providing exceptional weather resistance. This means that even in harsh outdoor environments, these coils maintain vibrant colors and intact coatings over long periods without fading or peeling. This feature makes them ideal for exterior walls and roofing applications.
Known for the combination of functionality and aesthetics, colored aluminum coils are widely used in construction, home appliances, signage and transportation.
Alloy | 1050, 1060, 1070, 1100, 3003, 5052, 5052, 5005, 5006, 5052, 5754, 5182 |
Thickness | 0.2-1.5mm |
Width | 10-1800mm |
Coating Surface | PVDF/ PE/HDP/FEVE/EOXY/ PU |
Coating Thickness | Single Coating (4-20 Um) |
Double Coating (25-28 Um) | |
Triple Coating (35-38 Um) | |
Temper | O,H12,H22,H14,H24,H16,H26,H18,H26,etc. |
Color | All Ral Color or As Request |
Type | Coil, Sheet, Strips, Plate, Foil |
Applications | Roofing System and Ceiling Decoration |
MOQ | 2 tons per size |
Standards and Specifications
ASTM | B209 |
ISO | ISO 26204 (alloy designations), ISO 6892 (mechanical testing),ISO 9001,ISO 14001. |
UNS | A91050 (United States Numbering System) |
PE(Polyester) Coating:
A common choice for outdoor applications due to its durability and resistance to fading.
PVDF (Polyvinylidene Fluoride) Coating:
Offers superior weathering, UV resistance and a long lifespan, often used for architectural applications.
Warrantly：
Regular PE: 3-5 years；
High Performance PE: 6-9 years；
PVDF: 15 years；
FEVE: Two coats: between 10-15 years
FEVE: Three coats: 15-20 years.
Technical Data:
Coating | POLYESTER | PVDF |
Item | Technical requirements | Technical requirements |
Thickness of coating film | ≥ 18 µm | ≥ 25µm |
Gloss deviation | gloss<70, tolerance≤10% | gloss<70, tolerance≤10% |
gloss≥70, tolerance≤5% | gloss≥70, tolerance≤5% | |
Hardness of pencil | ≥3H | ≥3H |
Adhesion | no lower than class 1 | no lower than class 1 |
Flexibility | ≤2T | ≤2T |
Boiling water resistance | no change (2h) | no change (2h) |
Color difference | ΔE≤2.0 | ΔE≤2.0 |
MEK | ≥100 times | ≥150 times |
Standard Colors
The standard color of colored aluminum sheet is modulated according to the RAL color card. The basic colors are red, yellow, blue, green, white, gray and other colors and their derivative colors, which are suitable for most conventional applications.
Metallic Colors
The Metallic color of colored aluminum coil simulate metal textures, such as silver gray, bronze, rose gold, etc., which add a sense of luxury and class to the product and are often used in high-end architectural decoration.
Printing Series
The printing series achieve natural texture effects such as wood grain and stone grain through special coating technology, providing more diversified choices for architectural design, esuitable for places that pursue natural and environmental protection concepts.
More details: Aluminum Coil Coating
Exceptional Durability:
High-performance PVDF coating resists fading, chalking, and corrosion for decades, even in harsh weather.
Wide Range of Aesthetics:
Available in a vast spectrum of standard and custom colors and finishes (metallic, matte, woodgrain) for any design.
Proven Compliance:
Manufactured to meet key North American standards (ASTM, CSA, AAMA 2605) for guaranteed performance.
Lightweight & Strong:
Provides structural integrity while being easy to handle and install, reducing overall costs.
Low Maintenance & Long-Lasting:
Stands up to the elements, requiring minimal upkeep over its long service life.
Application | Outdoor Applications | curtain wallboard, facades, solar collector, shutter doors, aluminum composite panel, roofing, gutter |
Indoor Applications | wall cladding, ceilings, bathrooms, kitchens and balconies, blinds,shutter doors, aluminum spacer | |
Advertisement and Market Applications | display platforms, signboards, fascia and shop fronts,license plate/name plate ,channel letter | |
Transportation | truck and container |
1) LCL by wooden pallet package, fumigation wooden pallet is available
2) FCL by wooden pallet package loaded in the container
3) FCL in bulk loaded in the container
4) Customized package according to your demands
Shipping:
7-15 days after receipt of payment(depend on order quantity)
